Galvanised sheets
Galvano, Tata Steel's innovative galvanised sheet boasts a zero-spangle finish, achieving unmatched smoothness and exceptional mechanical strength. This translates to remarkable versatility across applications.
Beyond its performance, Galvano also prioritizes the environment. Completely lead-free and RoHS compliant, it minimizes environmental impact. This eco-friendly design, combined with its unique chemistry, ensures exceptional performance without sacrificing the planet. Simply put, Galvano proves that superior quality and environmental consciousness can exist together.
.png)
FEATURES THAT DELIVER MORE
Trusted Brand Reputation
Backed by Tata Steel, a leading name in the steel industry, Galvano comes with a legacy of reliability and innovation.
Zero Spangle Finish
Galvano boasts a superior, smooth finish with "zero spangles." This enhances the visual appeal of your end product and allows for better paint adhesion.
Enhanced Formability
Galvano's zinc coating and high-quality steel substrate provide good formability. This allows for easier bending, shaping, and fabrication.
Environmentally Friendly
The Galvano coating is lead-free and RoHS-compliant, making it an eco-conscious choice.
Versatility
Galvano's superior versatility makes it suitable for various industries. From appliances and building components to solar structures and electrical applications.
Consistent Quality
Tata Steel's commitment to strict quality control measures ensures consistent material properties throughout each sheet of Galvano.
Superior Corrosion Resistance
Galvano is manufactured with high-quality steel and a rigorous zinc coating process. This ensures excellent protection against rust and other forms of corrosion.
Precision Tolerances
Tata Galvano is manufactured with precise dimensional control, ensuring tight tolerances in thickness and width.
FEATURES THAT DELIVER MORE
Precision Tolerances
Tata Galvano is manufactured with precise dimensional control, ensuring tight tolerances in thickness and width.
SEGMENTS & OFFERINGS
-
Appliances
Galvano is the preferred Zero-Spangled material of choice for appliance customers across India. It is present in a wide range of modern and stylish consumer durables such as Air Conditioners, Refrigerators and Washing Machines.
| Grade | DQ, IFCoating Thickness: 120 GSM, 275 GSM |
|---|
| Thickness Range | 0.5 mm - 1.2 mm |
|---|
| Width Range | 150 mm - 1540 mm |
|---|
-
Panels
Galvano has higher corrosion resistance, making it ideal for panel manufacture. It is used in for various Electrical and Telecom control panels, used not only in India but exported to other countries as well. The wide range of coating thickness ranging from 80 GSM to 275 GSM makes an ideal product for panels in different applications.
| Grade | CQ, DQ, EIFCoating Thickness: 80 GSM, 120 GSM, 275 GSM |
|---|
| Thickness Range | 0.5 mm - 1.2 mm |
|---|
| Width Range | 150 mm - 1540 mm |
|---|
-
Solar Structures
Galvano contributes to the cause of ensuring a clean and green environment by offering a wide range of products with strength levels going up to 350 MPa and coating thickness as high as 550 GSM. These are being used for manufacturing Module Mounting Systems (MMS) that are operational in several of the key solar installations across India.
| Grade | HSQCoating Thickness: 80 GSM, 120 GSM, 275 GSM, 450 GSM, 550 GSM |
|---|
| Thickness Range | 0.9 mm - 2.0 mm |
|---|
| Width Range | 1050 mm - 1300 mm |
|---|
-
Bus Body
The superior surface finish of Galvano ensures a better paint finish, which improves the aesthetic appeal of bus bodies. This is why OEMs and regional fabricators both prefer Galvano for bus body applications. Also, the wider SKUs allows manufacturers to minimize yield loss and save on processing costs.
| Grade | DQYS Range: upto 120 MPa |
|---|
| Thickness Range | 0.8 mm - 1.2 mm |
|---|
| Width Range | 1050 mm - 1540 mm |
|---|
-
Dish Antenna
Galvano has a major role to play in ensuring entertainment reaches the homes of consumers across the country. Due to the superior formability of Galvano, it is used to make the dish antenna used by all major service service providers in the country.
| Grade | IFCoating Thickness: 80 GSM, 120 GSM |
|---|
| Thickness Range | Thickness Range 0.9 mm - 2 mm |
|---|
| Width Range | 80 mm - 1540 mm |
|---|
-
General Engineering
Galvano finds widespread use in the General Engineering segment and is used for making several sheet metal components requiring bending & forming. It offers a wide range of steel chemistry for application specific requirements. The Product Application team of Tata Steel assists customers in selecting the right product and also creates novel chemistry to meet their specific needs. This makes Galvano a cost effective and superior quality offering preferred by fabricators across India.
| Grade | CQ, DQ, DDQCoating Thickness: 80 GSM, 120 GSM, 275 GSM |
|---|
| Thickness Range | 0.4 mm - 2 mm |
|---|
| Width Range | 900 mm - 1540 mm |
|---|
-
Pre-Engineered Buildings
Galvano offers high strength and superior corrosion resistance for which it is widely used in making structural components of PEBs such as purlins.
| Grade | HSQCoating Thickness: 80 GSM, 120 GSM, 275 GSM, 450 GSM, 550 GSM |
|---|
| Thickness Range | Thickness Range 1.0 mm - 2.0 mm |
|---|
| Width Range | 900 mm - 1250 mm |
|---|
